Insacal Conductivity FLXA Dual is a solution for both low and high conductivty.
The Dual version provides flexibility where multiple measurement ranges must be handled with a single setup - ideal for laboratories and service departments where both documentation and versatility are key.
Why Choose Insacal Conductivity FLXA Dual?
With the ability to cover both low and high conductivity in a single setup, FLXA Dual offers unmatched flexibility. It supports efficient workflows, reduces the need for multiple standards, and delivers the documentation required for professional calibration environments.
A practical choice where versatility and reliability must go hand-in-hand.
Best suited for
- Calibration Technicians who need to switch between PW/WFI and process-water ranges quickly
Technical Highlights
- Covers both low and high conductivity ranges
- Flexible and versatile single-setup calibration
- Delivered fully certified and traceable
Intuitive touchscreen operation
Insacal Conductivity is operated via a high-resolution touchscreen with an intuitive user interface, allowing straightforward navigation between menus. The home screen displays the reference value, temperature and measured conductivity in real time. For improved traceability and to prevent inadvertent changes, settings – including the cell constant – can be password-protected. The software supports multiple languages.
Portable use with no permanent installation required
Insacal Conductivity is compact and weighs less than 7kg. Its robust construction and integrated handle make it easy to transport to the point of use, enable reliable on-site calibrations wherever required. As the Insacal Conductivity electrode(s) can be placed directly in a beaker or installed in a flow-through fitting, no permanent installation is necessary.
Key Features
- Flexible dual-range measurement
Covers both low (PW/WFI) and high (process water) conductivity. - Versatile calibration solution
Reduces the need for multiple setups. - Accredited and traceable
Delivered with certified calibration and complete documentation. - Reliable performance
Suitable for labs and service departments handling multiple ranges. - GMP-ready records
Full documentation for QA and validation purposes.
Request your conductivity calibration solution today
KONTAKT VORES EKSPERT
Dorte Krüger Molin
Export Manager
Tel.: +45 2761 4503
Email: Dorte.Molin@insatech.com
| Specifications | |||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Touch screen HMI | Yes |
||||||||||||||||||
| Interface language | Multiple |
||||||||||||||||||
| Electrode | Yokogawa |
||||||||||||||||||
| Sensor cable length | 2 m (low range) 3 m (high range) |
||||||||||||||||||
| Standard flow fitting | ½" NPT female or mini-clamps |
||||||||||||||||||
| Conductivity range | Low range: 0.055 to 1000 µS/cm @ 25 °C |
||||||||||||||||||
| Cell constant determined | Low range: Standard solution at 100 µS/cm combined with an electrical calibration |
||||||||||||||||||
| Cell constant calibrated to (accredited) | Low range: 0.34% (by standard solution method) |
||||||||||||||||||
| Temperature range | Calibrated range: 0 to 90 °C (± 0.50 °C) |
||||||||||||||||||
| Transmitter type | FLXA402 + SA11 |
||||||||||||||||||
| Signal processing | Analogue + digital (selectable via SA11) |
||||||||||||||||||
| Physical configuration | Mounted in cabinet |
||||||||||||||||||
Didn't find what you were looking for?
Fill out the contact form and we will get back to you as soon as possible.
Product specification and manuals
-
Datasheet Insacal Conductivity FLXA
English | pdf
